Rotork offers third generation Skilmatic for failsafe actuation
The Rotork Skilmatic SI self-contained electro-hydraulic valve actuator combines all-electric simplicity with the precision of hydraulic actuation and the reliability of mechanical failsafe operation. Typical applications for Skilmatic actuators include functional safety related Emergency Shutdown (ESD) and Remotely Operated Shutoff Valve (ROSoV) duties.
Skilmatic's control and monitoring system has now been further developed with the introduction of the 3rd Generation, incorporating proven Rotork IQ3 intelligent electric actuator technology. Communication and data logging capabilities have been increased in response to end users' desire to access more valve related data, both in the field and in the control room.
The 3rd Generation of the SI actuator will consist of four models with multiple actuator sizes known as SI³-1, SI³-2, SI³-3 and SI³-4, enabling Rotork to offer quarter-turn failsafe actuation from 65Nm up to 600,000Nm for functional safety applications. As part of the development Rotork has enhanced the range by introducing the new SI³-3 standard range of spring return actuators with a torque range of 2,000Nm to 20,000Nm. This new range offers a choice of operating speeds, additional ESD options with single or dual inputs and enhancements to partial stroking to meet a wide range of applications.
Skilmatic SI 3rd Generation actuators combine established features including non-intrusive setting, performance monitoring and configurable data logging with an extended torque output range, increased functionality and enhanced availability of valve and process data for asset management and data analysis, displayed in a new, large and information-rich format.
Constructed for challenging environments, SI 3rd Generation actuators are designed to deliver a reliable means of valve management and positioning a valve to a safe condition. Safe valve positioning is selectable for failsafe to open, failsafe to close or lock in position on either loss of power or a range of programmable ESD signal options.
The SI 3rd Generation control module facilitates non-intrusive commissioning by means of a hand held setting tool with infra-red and Bluetooth interfaces. Settings including internal hydraulic pressure, position, limits, control, alarm and indication functions can be accessed and adjusted using user-friendly Rotork 'point and shoot' menus. Actuator status, control and alarm icons are provided on an advanced new dual-stack toughened glass illuminated display which also gives access to real-time information such as pressure, diagnostics and help screens.
Data from the actuator can be transferred to a PC for storage and analysis by means of Rotork Insight2 software. Offering flexibility of customisation to suit the application, the actuators can be integrated into the majority of digital bus control systems, including Pakscan, Foundation Fieldbus, DeviceNet, Profibus, Modbus and HART.
Designed for functional safety applications to SIL2 (1oo1) and SIL3 (1oo2) for use on safety critical applications, the actuators are also offered with enhanced partial stroke testing (PST), enabling valves to be function tested without affecting the process.
Performed either locally with the setting tool or remotely from the control room via hardwire or fieldbus communications, PST tests all the final elements (actuator and valve) by measuring the time to move to a set position whilst monitoring the pressure. PST results are recorded by the integral datalogger, shown on the display screen and optionally remotely indicated.
All actuators are available with hazardous area certification encompassing ATEX, INMETRO, IEC, FM, CSA and GOST. The double-sealed electric enclosure is watertight and dustproof in ratings up to IP68 (submersed to a depth of 7m for 72 hours). Specifiable for three-phase, single-phase or DC electrical power supplies, the Skilmatic SI3 range delivers a range of rotary torque or linear thrust outputs that are suitable for valves of virtually any size and design.
