Control valves for high pressure injection applications

Badger Meter HP-60 ultra-high pressure control valves are ideal for offshore, oil and gas control applications with up-stream pressures of up to 60,000 psi. Available in the UK through liquids handling specialists Pump Engineering, the Type HP-60 control valve utilises a 17-4 PH body along with a solid Stellite inner valve assembly.

The HP-60 valve is also ideal for use in industrial research and process pilot plants on liquids and gases, with typical applications being chemical injection, for example in the production of high pressure, low density polyethylene (HPLDPE).

Standard features include, pressure rating to 60,000 psi at 37.7ºC, a wide range of interchangeable trims, choice of linear or quick opening trims, ANSI Class lll shutoff (size P-1 through P-9) and ANSI Class lV shutoff (size K through O). The inner valve (plug and seat) is constructed from solid Stellite while titanium nitride coated Stellite is available as an option. Standard packing is Torlon/PFA CV rings.

For lower pressures up to 350 bar, the standard RC200 valve in 316 stainless steel is available with a larger range of trims. All the valves can be supplied with standard (air-to-open, air-fail-close, air-to-close, air-fail open) actuators. However, actuators in stainless steel with integral top mounted positioner or side mounted positioner, are also available.

A wide range of accessories, such as filter regulators, gauges, I/P converter, limit switches and solenoids, are also offered.
