Centork announces worldwide launch of CK modular valve actuation system
Actuator developer Centork recently launched its new range of modular electric valve actuators at the 2014 Valve World Expo.
Designed to deliver a solution for duties and applications of all descriptions across a range of industries, the CK range's modular, 'building block' construction presents a number of options and features, enabling each actuator to precisely match its specific valve duty and function. The choice ranges from basic actuators requiring separate motor controls to sophisticated versions equipped with the state-of-the-art Centronik intelligent digital control unit.
Centronik provides integral control with data logging for diagnostics and asset management. The module is compatible with hardwired, digital or analogue control protocols and offers cost-effective integration with centralised and distributed control systems.
Non-intrusive, password protected configuration is performed using the actuator selector switches or the hand-held Centork Setting Tool, using infra-red or Bluetooth interfaces. The Centronik display provides position indication, status and alarms, plus user-friendly menu-driven configuration screens.
Centork CK actuators provide isolating or modulating control of multi-turn, part-turn or linear valves. Operating from single-phase or three-phase electrical supplies, all actuators are environmentally sealed to IP68 against an 8m head of water for a maximum of 96 hours continuous submersion with 10 electrically powered operations permissible whilst submerged. Plug and socket connections for power supplies and between modules assist swift site wiring and provide a simple connection platform for upgrades and modifications.
CK actuators are manufactured in a range of three frame sizes complying with international actuator design standards EN15714-2 and EN ISO 5210. Manual handwheel operation, designed to standard EN12570, is independent of the motor drive and selected with a lockable hand/auto lever acting on a safe, low speed clutch. All actuator sizes can utilise separate thrust or non-thrust bases, enabling actuators to be removed from the valve without affecting valve position.
The CK Range maximum multi-turn output torque is 6,800 Nm (5,030 lbf.ft), whilst part-turn torque up to 200,000 Nm (147,600 lbf.ft) is achieved in combination with secondary gearboxes. The torque range facilitates reliable operation of valve types and sizes typically found in industries such as power generation and water treatment.
