New multi-function Coriolis mass flowmeter from Badger Meter

Badger Meter’s new RCT1000 Coriolis mass flowmeter is capable of measuring several liquid properties simultaneously
Badger Meter’s new RCT1000 Coriolis mass flowmeter is capable of measuring several liquid properties simultaneously

Badger Meter has introduced RCT1000 Coriolis mass flowmeters, the latest addition to its line of flow instrumentation products.

The RCT1000 provides the ability to simultaneously measure mass, volume, density, and temperature, providing control options to synchronise precision processes.

‘More than simply a flow meter, the RCT1000 Coriolis flow system is capable of controlling process flow by sending commands to other instrumentation, such as valves and pumps,’ says Cheryl Ades Anspach, marketing manager at Badger Meter.

‘The RCT1000 transmitter performs batch and PID control, which eliminates additional control equipment. This means one Coriolis flowmeter interface functions as a transmitter and an economical mini-process control system, which can operate independently or be integrated into a larger system.’

Complementing the transmitter and sensor, every RCT1000 unit comes with the RCT Console software package.

RCT Console is specifically designed to provide users greater operational flexibility and ease-of-use.

By allowing users quick access to configure measurement parameters through the RCT Console software or the LCD interface on the transmitter, the meter can be set up and measuring flow in a matter of minutes.

RCT Console is also capable of providing advanced data logging and performance trend analysis, as well as system verification provided by the HealthTrack feature which records critical parameters and compares them to normal ranges.

The Badger Meter RCT1000 Coriolis mass flowmeter identifies flow rates by directly measuring fluid mass over a wide range of fluid temperatures and viscosities with a high degree of accuracy.

Furthermore, the unobstructed, open flow design and measurement technique makes the RCT1000 suitable for a variety of fluids, such as vegetable oils and fats, slurries, adhesives, coatings and hardeners, and other viscous, nonconductive fluids that are difficult to measure with other technologies.

RCT1000 Specifications
• Pipe size: 1/16 to 3”
• Accuracy:
- Liquids: up to ±0.1% of flow rate ± zero stability
- Gases: up to ±0.5% of flow rate ± zero stability
- Density: up to ±0.03121lb/ft3
• Zero stability: up to ±0.025% of full scale
• Repeatability: up to ±0.05% of flow rate
• Process temperature range: -40 to 200°C
• Wetted material: 316L stainless steel
